PhotoViewer

PhotoViewer is a JS plugin to view images just like in Windows.

Look at the following example:

Getting Started

All the pictures come from Flickr website, copyright to the original author.

Installation

$ npm install photoviewer --save

Quick Start

Step 1: Include files

@import 'photoviewer/dist/photoviewer.css';

import PhotoViewer from 'photoviewer';

or

<!-- Core CSS file -->
<link href="/path/to/photoviewer.css" rel="stylesheet">

<!-- Core JS file -->
<script src="/path/to/photoviewer.js"></script>

Step 2: Initialize

The usage of photoviewer is very simple, the PhotoViewer constructor has 2 argument.

  1. Array with objects of image info.
  2. Options
// build images array
var items = [
    {
        src: 'path/to/image1.jpg', // path to image
        title: 'Image Caption 1' // If you skip it, there will display the original image name(image1)
    },
    {
        src: 'path/to/image2.jpg',
        title: 'Image Caption 2'
    }
];

// define options (if needed)
var options = {
    // optionName: 'option value'
    // for example:
    index: 0 // this option means you will start at first image
};

// Initialize the plugin
var viewer = new PhotoViewer(items, options);

At last, binding click event on a button element, you should get the following example.

Initializing form a list of links

The default DOM structure as following:

<a data-gallery="manual" href="big-1.jpg">
  <img src="small-1.jpg">
</a>
<a data-gallery="manual" href="big-2.jpg">
  <img src="small-2.jpg">
</a>
<a data-gallery="manual" href="big-3.jpg">
  <img src="small-3.jpg">
</a>

You should get the image src and the index of element clicked manually to create the images array.

$('[data-gallery=manual]').click(function (e) {

  e.preventDefault();

  var items = [],
    // get index of element clicked
    options = {
      index: $(this).index()
    };

  // looping to create images array
  $('[data-gallery=manual]').each(function () {
    let src = $(this).attr('href');
    items.push({
      src: src
    });
  });

  new PhotoViewer(items, options);

});

Options

index number 0

The images array index. If 0, it will show first image when photoviewer opened.

draggable boolean true

If ture, it allow modal dragging.

resizable boolean true

If ture, it allow modal resizing.

movable boolean true

If ture, it allow image moving.

keyboard boolean true

Make photoviewer can be controled by keyboard. The shortcut key is similar to Windows photo viewer.

title boolean true

If ture, it will show image title on header.

fixedModalSize boolean false

This option will set photoviewer's size when it opened. If false, the modal initialized size will fit to image size. If true, the modal initialized size will be set with modalWidth and modalHeight.

modalWidth number 320

It's the modal min width or modal initialized width when opened.

modalHeight number 320

It's the modal min height or modal initialized height when opened.

gapThreshold number 0.02

The gap size threshold. There will have a gap if modal too large to beyond the browser. Its min value is 0, means the modal's width or height should be equal to browser window if it's too large.

ratioThreshold number 0.01

Image zoom ratio threshold.

minRatio number 0.1

The min ratio to show image. 0.1 means the image can be zoomed 0.1x from original size.

maxRatio number 16

The max ratio to show image. 16 means the image can be zoomed 16x from original size.

headerToolbar array ['maximize','close']

The buttons display in header toolbar.

footerToolbar array ['zoomIn','zoomOut','prev','fullscreen','next','actualSize','rotateRight']

The buttons display in footer toolbar.

fixedContent boolean true

If true, the document page can not scoll.

initMaximized boolean false

If false, the modal size will be set of image size or what you set with modalWidth and modalHeight. If true, the modal size will be set maximized when initialized just like other lightbox.

initAnimation boolean true

If false, it will not have animation at plugin's initialized.

fixedModalPos boolean false

If true, the modal position will be fixed when change images.

zIndex number 1090

The modal style of z-index, it is useful with multiple instances.

dragHandle string | boolean false

The handle of draggable. Default false which whole modal can be dragging.

multiInstances boolean true

If false, it can only open single photoviewer.

icons object

You can customize the icons class in following key.

i18n object

You can customize the buttons title in following key.

callbacks object

You can define callbacks in callbacks option.

new PhotoViewer(items, {
  callbacks: {
    beforeOpen: function(context){
      // Will fire before modal is opened
    },
    opened: function(context){
      // Will fire after modal is opened
    },
    beforeClose: function(context){
      // Will fire before modal is closed
    },
    closed: function(context){
      // Will fire after modal is closed
    },
    beforeChange: function(context, index){
      // Will fire before image is changed
      // The argument index is the current image index of image group
    },
    changed: function(context, index){
      // Will fire after image is changed
      // The argument index is the next image index of image group
    }
  }
});

progressiveLoading boolean true

If true, the image will be rendered progressively.

appendTo string 'body'

The DOM element to which viewer will be added.

customButtons object {}

new PhotoViewer(items, {
  footerToolbar: [
    ...
    'myCustomButton'
  ],
  customButtons: {
    myCustomButton: {
      text: 'custom!',
      title: 'custom!',
      click: function (context, e) {
        alert('clicked the custom button!');
      }
    }
  }
});

Each customButton entry accepts the following properties:
